Semi Auto Mineral Water Stretch Bottle Blow Moulding / Molder / Molding Machine / Equipment / Line / Plant / System

Name: Semi Auto Mineral Water Stretch Bottle Blow Moulding Molder Molding Machine Equipment Line Plant System
Brand: FillPack
Price: 1 USD

Semi Auto Mineral Water Stretch Bottle Blow Moulding / Molder / Molding Machine / Equipment / Line / Plant / System Manufactures

Brand Name : FillPack

Model Number : FP-120

Certification : CE. ISO9001

Place of Origin : China,JiangSu,Zhangjiagang

MOQ : 1 set/pcs

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, , MoneyGram

Supply Ability : 1 set / month

Delivery Time : 35-40 days after deposit receipt

Packaging Details : Sea worthy package

bottle volume : 5 gallon10L-20L(3-5Gallon)

Output : 120BPH

Cavitiy : 6 cavities

Outer Preform heater : 2670*680*1650mm

Power : 40kw

Weight : 1880Kg

Dimension : 2350*750*1900mm

Inner preform heater : 400*350*1200mm

Condition : New

Application : PET bottle

Automatic : Semi-auto

Blow moulding type : Stretch blow moulding

Voltage : 380V/220V 3 phase 50HZ / 60HZ / Customized

Warranty : 1 year

After-sales service provided : Engineers available to service machinery overseas

Contact Now

1 cavity semi-auto blow molding system for 5gallon

>>> Product Introduction:
FP-120 Bottle Blowing Machine Manufacturer with one cavity is especially used to produce 3 gallon and 5 gallon bottles and is widely used to produce any shape of plastic from PET with neck finishes from 15mm-200mm.

>>> Product Features:

● Perfect function with economic investment.
● Small size and compact construction with no space waste.
● Easy to operate and maintain ,operation by one person.
● Saving power and uneasy to worn out ,Adopting new double crank four bars to lock mould, the cross fixed. Providing high pressure blowing system.
● We can provide performs and various bottle& cap molds for 5 gallon and 3gallon bottles to meet customer's requirements.

Semi Auto Mineral Water Stretch Bottle Blow Moulding / Molder / Molding Machine / Equipment / Line / Plant / System

>>> Flow and Auxiliary machines:

HP Air Compressor → Air Tank → Air Filter →Air Dryer → Air Filter → Chiller → LP Air Compressor →Automatic Bottle Blowing Machine

1. PET Bottle Mold Our PET blowing machine can produce various shape bottles. we can according to your need to design your own bottle and make mold for you.

2. Preform & Cap Molds We also can provide you with preform mold and cap mold according to your demand.

>>>Technical Paramters:

Container	Product material	PET
	Volume	10L-20L(3-5Gallon)
	Output	150PCS/H
	Max bottle length	430mm
	Max bottle diameter	300mm
Moulding	Stretching stroke	450mm
	Clamping force	6000kg
	Mould opening stroke	360mm
Machine size and weight	Main machine	23507501900mm/1500Kg
	Heater	26706801650mm/380Kg
	Power	40kw
